Vapor Phase Reflow and Rework Systems

  • Model RD3 Batch System

    • The biggest baddest vapor phase on the planet
    • 625mm x 625mm working envelope
    • Convected preheat zone
    • Working fluid filtration
    • Dual speed clamshell cooling
    • 10” OIT with password protection and 250 recipes
    • Much more
    • The RD3 was designed around our big board customer’s needs in the field.
  • RD52 Inline Vapor Phase Reflow Oven

    Model RD52 Inline System

    • Need it to go faster? Inline vapor phase reflow the way it should be.
    • Left to right product flow
    • 450mm x 380 mm working envelope
    • 4 zone clamshell preheat section
    • SMEMA communications
    • Password protection
    • Unsurpassed reflow profile control
    • Perfect for high volume automated inline vapor phase processing
  • Model RD10 Belted Inline System

    Model RD10 Belted Inline System

    • Great for mechanical attachment
    • High volume continuous production
    • Left to right flow
    • 200 mm belt width
    • Optional sizes available
  • RD2 Vapor Phase Reflow System

    Model RD2 Batch System

    • Our biggest seller, great for virtually all vapor phase reflow applications
    • 460mm x 380mm working envelope
    • Convected preheat zone
    • Vapor preheat function
    • Working fluid filtration
    • Working fluid auxiliary storage
    • Process recipe storage
    • All Standard
    • Perfect for medium sized product and volume requirements
  • desc

    V-Works 24 Vapor Phase Rework System

    • First and only single component vapor phase rework system in the world
    • Unsurpassed uniformity
    • Global bottom side preheat
    • 50 mm x 550 mm working envelope
    • Vision / Placement
    • Recipe storage
    • Makes the hard rework jobs easy
  • RD1 Vapor Phase Reflow System

    Model RD1 Batch System

    • Big performance in a small package
    • 305mm x 255mm working envelope
    • Convected preheat zone
    • Vapor preheat function
    • Working fluid filtration
    • Working fluid auxiliary storage
    • Process recipe storage
    • All Standard
    • Does everything its big brothers do in a smaller footprint and price range.

R&D Technical Services is now R&D VaporTech an IBL company!

Please contact us at our new phone number 952-217-4407

Vapor Phase Reflow and Rework Systems From R&D VaporTech

R&D VaporTech has been the innovation leader in vapor phase technology since 1996. It's award winning systems have been honored with awards such as an SMT Vision Award for it's ground breaking inline Vapor Phase Reflow Oven the Model RD52, as well as, two Global SMT & Packaging Awards and two Circuits Assembly New Product Awards for its Vapor Phase Rework system the V-Works 24. The first and only product of its kind.

R&D VaporTech prides itself on delivering the highest quality highest value vapor phase reflow and rework equipment in the world. With our innovative designs and unsurpassed quality and customer support, we continue to lead the industry in vapor phase technology.

Our systems are used in a wide variety of industries including Mil/Aero, Medical, Mechanical Attachment, High Reliability Processes, Contract Manufacturing. Our customer list is a virtual who's who of the world finest electronic manufacturers. We offer a full line of vapor phase reflow ovens from small table top batch systems to fully automated high volume inline systems.

With our extensive knowledge of vapor phase, equipment, technology, process and materials, R&D VaporTech is the only contact you need for a successful transition into the unsurpassed reflow technology that is Vapor Phase.
